Single Axis Copy Router

Get a Price/Quote

Product Details:

Rotation Single Axis
Model Standard
Product Type Single Axis Copy Router
General Use Copy routing aluminium and PVC profiles
Material Mild Steel, Aluminium
Type Copy Router Machine
Capacity Suitable for up to 3 mm Aluminium/Profile
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Single Axis Copy Router Price And Quantity

Minimum Order Quantity one Piece

Maximum Routing Depth 40 mm
Accessories Included Copy templates, collets, wrenches
Profile Compatibility Aluminium, PVC, and light metals
Noise Level Below 80 dB
Safety Features Interlocked safety guard, emergency stop
Clamping System Quick pneumatic or manual clamping
Copy Template Movement Single Axis X/Y

Single Axis Copy Router Product Specifications

Material Mild Steel, Aluminium
Power 1.1 kW
Product Type Single Axis Copy Router
Spindle Speed 12000 rpm
Control System Manual Operation
Table Size 450 x 130 mm
Color Blue/Grey
Capacity Suitable for up to 3 mm Aluminium/Profile
Type Copy Router Machine
Computerized No
General Use Copy routing aluminium and PVC profiles
Feature High Precision, Robust Structure, Easy Operation
Table Slide Way Linear bearings
Weight (kg) Approx. 150 kg
Model Standard
CNC Or Not Not CNC
Dimension (L*W*H) 900 x 700 x 1400 mm
Voltage 230 V, 50 Hz
Rotation Single Axis
Floor Space 850 x 700 mm

Maximum Routing Depth 40 mm
Accessories Included Copy templates, collets, wrenches
Profile Compatibility Aluminium, PVC, and light metals
Noise Level Below 80 dB
Safety Features Interlocked safety guard, emergency stop
Clamping System Quick pneumatic or manual clamping
Copy Template Movement Single Axis X/Y

Single Axis Copy Router Trade Information

Payment Terms Telegraphic Transfer (T/T)
Supply Ability 30 Piece Per Month
Delivery Time 20 Days
Packaging Details in wooden case
Main Export Market(s) South America, Africa, Australia, Middle East, Asia

Product Description

Backed by the team of experienced professionals, we are able to manufacture and export a precision engineered range of Single Axis Copy Router. This router is manufactured using high quality components by our professionals. Our router is extensively used in various industries for various purposes in many industries. Widely acknowledged by our clients due to its superior performance, trouble free operation and longer service life, we offer this Single Axis Copy Router to the clients in different specifications as per their specific needs.

Specifications:

available for copy milling and drilling holes on aluminum profile
with template can copy milling different slots, such as lock hole, water leakage hole.

MAIN TECHNIQUE PARAMETER

Worktable size (WxH)	620x260mm
Max. distance of milling head from left to right	240mm
Max. distance of milling head from front to rear	120mm
Max. space height of milling head	220mm
Milling cutter diameter	3mm / 5mm / 8mm
Milling cutter rotation speed	12000 rpm
Milling cutter motor power	1.1 Kw
Drilling cutter motor power	1.1 Kw
Motor rotation speed	2840 rpm
Min. distance between each hole	20mm
Max. distance between each hole	112mm
Milling cylinder feeding travel	50mm
Drilling cylinder feeding travel	100mm
Working air pressure	0.6-0.8Mpa
*Overall dimension (L WH)*	720(2520)x1200x1550mm
Weight	450Kg

Efficient Copy Routing Performance

Engineered for reliability, this copy router delivers high precision machining for aluminium and PVC profiles using single-axis X/Y movement. Its linear bearing ways ensure smooth, accurate table slides, while the maximum routing depth of 40 mm accommodates diverse routing needs. Pneumatic or manual clamping provides flexibility for different work environments.

User-Focused Safety and Functionality

The router is equipped with integrated safety featuresan interlocked guard and emergency stopprioritizing user protection. With noise levels below 80 dB and straightforward manual controls, operators benefit from a comfortable and controlled working environment while easily managing daily routing operations.

FAQs of Single Axis Copy Router:

Q: How does the single axis copy router handle different profile materials?

A: This machine is engineered for aluminium, PVC, and light metals. With adjustable templates and clamping options, it securely holds and routes profiles up to 3 mm in thickness, ensuring clean and consistent results across compatible materials.

Q: What safety features are integrated with the copy router?

A: The router is fitted with an interlocked safety guard that prevents accidental contact during operation and an emergency stop button for immediate shutdown in case of any hazard, ensuring maximum operator protection.

Q: When should I opt for pneumatic clamping instead of manual clamping?

A: Pneumatic clamping is ideal for higher-volume or repetitive tasks, providing quick and uniform securing of workpieces. Manual clamping suits lower-volume or custom jobs where flexibility and control are needed for unique profiles or setups.

Q: Where can this copy router be installed for optimal operation?

A: Thanks to its compact footprint (850 x 700 mm floor space), the machine can be installed in small to medium manufacturing facilities or workshops. Place it on a stable, level surface with adequate electrical supply (230 V, 50 Hz) and ventilation.

Q: What is the process of setting up and using this copy router?

A: Installation involves assembling the accessories (templates, collets) and connecting the power supply. Secure the profile using the clamping system, select the proper template, and set the desired routing depth. Operate the spindle and guide the movement along the X/Y axis to complete the routing task.

Q: What benefits does this copy router provide manufacturers and suppliers?

A: Manufacturers gain precision routing, efficient operation through its robust structure, and ease-of-use via ergonomic controls. Its safety features, quiet operation, and compatibility with common profile materials make it suitable for production settings focused on quality and productivity.
