Home » Products » Aluminum Cutting Machine » 90 Degree Single Head Saw

90 Degree Single Head Saw

90 Degree Single Head Saw
90 Degree Single Head Saw
Send Inquiry
Product Code : KT-328C
Brand Name : Kingtool
Price And Quantity
  • Minimum Order Quantity
  • one
  • Unit of Measure
  • Piece/Pieces
Product Specifications
  • Product Type
  • KT-328C
  • General Use
  • cutting
  • Material
  • Aluminum
  • Type
  • Metal Cutting Machine
  • Weight (kg)
  • 700 Kilograms (kg)
  • Computerized
  • No
  • Automatic
  • No
  • Control System
  • semi automatic
  • Cutting Function
  • Semi Automatic
  • Blade┬áSize
  • 500mm
  • Drive Type
  • Electric
  • Dimension(L*W*H)
  • 4600X900X1400mm Millimeter (mm)
  • Feature
  • Good Quality, High Efficiency, Low Energy Consumption
Product Description

We are remarkable entity, engaged in offering superior range of Single Head Saw in 90 degree which vertically cuts through the material in an efficient manner. This saw has been appreciated for precision designing, optimum performance, robust construction and reliability. Made up using high grade raw materials under the guidance of skilled team of professionals, this Single Head Saw in 90 degree is broadly demanded in the global market. To meet the wide needs of clients, this is offered in different specifications.

Specifications:

1- with 500mm(20' saw blade)
2- only for 90 degree angle cut to length
3- with 2*3m racks on left and right side

MAIN TECHNIQUE PARAMETER

1.

Saw cutting length

80~2000/3000mm

2.

Saw cutting (WXH)

230x150mm

3.

Main motor power

4Kw

4.

Main motor rotation speed

2840 rpm

5.

Saw blade dimension

500X30X120T

6.

Saw blade feeding speed

0-3m/min

7.

Saw blade returning speed

2-3m/min

8.

Working air pressure

0.6-0.8Mpa

9.

Overall dimension (LXWXH)

4600X900X1400mm

10.

Weight

800Kg


Trade Information
  • Payment Terms
  • Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T)
  • Supply Ability
  • 20 Per Month
  • Delivery Time
  • 25 Days
  • Packaging Details
  • in wooden case

FOSHAN SHUNDE KINGTOOL ALUMINUM PROCESSING MACHINERY CO., LTD.
